ML620Q536

General-purpose 16bit MCU

ML62Q1622

Date : Mar.30.2017

1600 Group has an LCD driver.
This Group is a high performance, low-power and safe RISC microcontroller with an LCD driver and a 16-bit original CPU 'U16 Core' of LAPIS Semiconductor.
This group has a lineup of the microcontrollers with 48 to 64 pins, 32 to 64KB flash memory.
In addition to the noise immunity inherited from the tough microcontroller,
newly advanced safety functions expand the application in household appliances or industrial instruments.

  • Specification
  • Documents
  • Tool/Software
Operating COnditions
Operating voltage(V) 1.6 to 5.5
Operating Frequency(Max.) Low speed:32.768kHz/(Internal RC oscillation/Crystal oscillation), High speed:24MHz//(PLL oscillation)
Min. Exec time 41ns/30.5μs
Current consumption(Typ.@HALT) 3.4/2.2μA/(Internal RC/Crystal
Operating Temperature(°C) −40 to +105
ROM/RAM
ROM type Flash
ROM capacity(Byte) 64K
DataFlash capacity(Byte) 2K
RAM capacity(Byte) 4K
Function/Features
Input
output
InputOutput 53
8bit timer 6/(8bit×12)
16bit MultiFunctions Timer 6/(TMR, PWM, IGBT, Capture)
PWM -
Capture -
WDT 1
ADC 10bit×12(SA type)
I2C Master Slave×1/Maste
UART -
Voltage detection VLS×1
LCD driver Max.288dot35seg.×8com.
External interrupt 8
Remarks Comparator×2,DMA,MPY
Others
Others
Package P-QFP64-1414-0.80/P-TQFP64-1010-0.50
Chip support -
ML62Q1600 Group datasheet
Contents Version Date Download
ML62Q1600 Group datasheet 5 2018/05/31
pdf
ML62Q1400/1600 Group User's Manual
Contents Version Date Download
ML62Q1400/1600 Group User's Manual 4 2019/02/08
pdf
ML62Q1622 MCU Starter Kit Guide
Contents Version Date Download
ML62Q1622 MCU Starter Kit Guide - 2017/09/07
pdf
ML62Q1200 1400 1600 Characteristics graphs
Contents Version Date Download
These graphs are reference for designing an application. - -
pdf
Implementation specifications
Package code Contents Download
P-QFP64-1414-0.80-ZK6 Outline and Dimension, Recommended Reflow Conditions, Shipment Package Specification, Mounting area for package lead soldering to PC boards, Marking Layout
pdf
P-TQFP64-1010-0.50 Outline and Dimension, Recommended Reflow Conditions, Shipment Package Specification, Mounting area for package lead soldering to PC boards, Marking Layout
pdf
Environmental data
Package code Contents Download
P-QFP64-1414-0.80-ZK6 RoHS Certificate of Compliance, Reach Certificate of Compliance, List of ingredient substances, SOC Analysis Report
pdf
P-TQFP64-1010-0.50 RoHS Certificate of Compliance, Reach Certificate of Compliance, List of ingredient substances, SOC Analysis Report
pdf
